WR49
Howell
HM-WR49
Silicone weather-resistant adhesive for construction
HM-WR49 silicone weather- resistant adhesive for construction is a kind of one-component, neutral curing, low modulus, high elasticity silicone rubber; it has good elasticity and displacement deformation ability, and has good adhesion to various powder coating metals The thixotropy of the product prevents it from sagging when it is applied in building joints, so it is especially suitable for the design of non-structural bonding, weather resistance, and waterproof sealing of various curtain walls; at the same time, it can be used in a wide range of climate temperatures It can be used, and it has good adhesion and compatibility to the surface of most substrates without primer. After curing, it is anti-aging, anti-ultraviolet radiation and extreme high and low temperature (-50- 150°C) changes; it has Low modulus performance, can bear the expansion and displacement capacity of the interface ± 25%, can be widely used in bonding and sealing
◆ Application of glass curtain wall, aluminum-plastic panel curtain wall, door and window sealing and caulking
◆Non-structural adhesive assembly application of various curtain walls
◆ Application of sealing and caulking between various metal and aluminum alloy doors, windows and walls
◆Glass, coated glass, tiles and masonry, concrete, etc.
◆Wood that does not seep oil
| Sagging (mm) | 0 |
Complete curing time (humidity 50±5%, temperature 23±2℃) | 14-21 days |
Surface drying time (h) | ≤2 |
Depth curing rate | 2 mm/day |
Hardness (Shore A) | 35 |
Tensile modulus at 25% elongation (MPa) | 0.16 |
| Tensile modulus at 50% elongation (MPa) | 0.36 |
| Tensile modulus at 100% elongation (MPa) | No break |
| Ultimate tensile modulus (MPa) | 1.2 |
| Ultimate elongation% | 400 |
Grade of sealant | 25HM |
The above data is tested at 25℃ and 50% relative humidity. After cured for 21 days at a humidity of 50±5% and a temperature of 23±2℃ Standard colors are white, black, gray, and transparent. Other colors can be provided according to customer needs. | |
HM-WR49 is a one-component sealant, which can be cured after contact with water vapor in the air. It is easy to operate and does not need to be stirred before use. It can be applied by manual or pneumatic glue gun. Before sizing, ensure that the surface of the base material is dry and free from pollution such as oil, grease and dust. After sizing, the glue surface must be repaired before the surface of the glue is crusted; when designing the glue joint, three-sided bonding of the sealant should be avoided. Usage Limitations
◆ Cannot be used for structural assembly
◆ Cannot be used on the surface that will seep plasticizer or solvent, which may cause permanent damage to the sealant
◆ It is not recommended to be used in a completely sealed space, because it will not be fully cured due to lack of water vapor
◆ Not recommended for long-term immersion in water
◆ It is not recommended to be used on structural surfaces that will directly contact food
◆ It is not recommended to be used on medical devices Testing The customer is responsible for conducting appropriate testing of the recommended sealant for their specific application and determining whether its performance meets their requirements. Adhesion Test - Nanjing Howell New Material Technology Co., Ltd. has the ability to test the adhesion of Howell products to the materials selected for the project and will provide appropriate product recommendations and surface cleaning methods in writing to the customer. Compatibility Test - To ensure the compatibility of engineering materials (such as aluminum profiles, gaskets, pressure strips, and double-sided adhesive tape) with Howell sealants, a compatibility test must be conducted before using the product for engineering purposes . The customer can either conduct the test themselves or provide the materials to Nanjing Howell New Material Technology Co., Ltd.'s laboratory, where the company will conduct the compatibility test between its product and the materials and provide the results in writing to the customer.
Packaging:
Standard packaging includes 300ml plastic cartridge with 24 pieces per carton;500ml soft film packaging, 20 pieces/box; 200L/Iron drum.
Storage and Shelf Life:
Store the original sealed adhesive in a dry place with a temperature not exceeding 27 degrees. The storage period is 12 months from the date of production.
